Single workstation
ONE HOST
VECTOR
Mesh / DDS
Selected services
Run the app and required services locally. Prepared maps and models remain available without online imagery.
SYSTEM COMPOSITION
One interface.
Independent components.
VECTOR presents the workspace. Services connect data and perform specialist tasks. Mesh links participating components through DDS.
VECTOR App
Operator interface + native DDS gateway
Supported state, requests & replies
Mesh / DDS
Publish / subscribe · typed data · configured domain
Independent service participants
Mission services
Geometry services
Device adapters
DIRECT TO THE APP
Video delivery
RTSP / WebRTC
Decoded media follows the configured streaming path.Maps & models
Local datasets / data services
Prepared geometry and textures are loaded by the map renderer.DEPLOYMENT
Start on one machine.
Connect across hosts.
Place the services where the operation needs them. Connected DDS participants need a matching domain and reachable network configuration.
Connected hosts
Workstation A
Workstation B
Mesh / DDS domain
Service host
Run services on reachable hosts and connect the workstations that need their data. App views and local datasets stay independently configured.
Windows & LinuxApp, Mesh and service builds target both platforms. Validate the chosen runtime and network combination for deployment; local model processing is currently verified on Linux.
EXTERNAL INTERFACES
Connect at the boundary.
Adapters translate source-specific protocols into the data and actions supported by the workspace.
Aircraft & traffic
Vehicle state, cooperative traffic and supported commands.
MAVLink 1 & 2 · NMEA · AIS · ASTERIX
Selected autopilot and surveillance adapters.Sensors & video
Video streams, sensor metadata and supported payload control.
STANAG 4609 / KLV · RTSP · WebRTC
Media transport and metadata follow distinct paths.Geospatial data
Prepared maps, external imagery and local model datasets.
Local map packages · WMS · OBJ / GLB / CityGML
Dataset format and geographic placement define the import.External systems
Exchange supported operational objects with other applications.
MQTT · REST · TAK / CoT
Adapters map external messages into the common data model.Available data and commands depend on the selected adapter, equipment and deployment configuration.
